Mesh Eigen Functions & Spectral Analysis

1 Why the Laplacian?

We have a 3D mesh - a human body, a teapot, a scanned face. It's a cloud of vertices connected by edges and triangles. Now suppose we want to study how some quantity (temperature, color, displacement) varies across the surface.

On a smooth surface, the tool for this is the Laplacian operator ∇². Think about heat diffusion. If vertex i sits at 100° and all its neighbors sit at 20°, heat flows outward fast. If vertex i matches its neighbors exactly, nothing happens. The Laplacian captures exactly this intuition.

On a mesh we don't have a smooth surface, we have discrete vertices and edges. So we need a discrete Laplacian that approximates the continuous operator on our graph structure.

2 The discrete Laplacian on a mesh

Let f be a scalar function on the mesh - one number per vertex (temperature, height, color, whatever). The combinatorial Laplacian at vertex i is:

The second derivative literally is the neighbor-average difference.

As a matrix

Since f is a vector (N numbers, one per vertex), L can be written as an N×N matrix. The entries are beautifully simple:

For 3 vertices all connected to each other, L looks like:

3 Eigen functions: the mesh's natural patterns

Since L is a matrix, we can ask the classic eigenvalue question: are there special functions f where applying L just scales f without changing its pattern?

A mesh with N vertices has exactly N Eigen functions f₁, f₂, …, fₙ with eigenvalues λ₁ ≤ λ₂ ≤ … ≤ λₙ. Each Eigen function is just a vector of N numbers - one value per vertex - describing a pattern across the surface.

Computing Eigen Functions in practice

Mesh Laplacians are sparse - each vertex connects to only ~6 neighbors out of thousands, so L has mostly zeros. Use sparse solvers:

# Dense (small meshes)
eigenvalues, eigenvectors = numpy.linalg.eigh(L)

# Sparse (large meshes - much faster, only compute K smallest)
eigenvalues, eigenvectors = scipy.sparse.linalg.eigsh(L, k=50)

4 Small λ vs large λ - the frequency story

The eigenvalue λ tells you about the frequency of the Eigen function pattern. This follows directly from Lf = λf:

This is called spectral geometry - and it's why people talk about the "frequency domain" of a mesh. Small λ = low frequency = smooth. Large λ = high frequency = detail / noise.

5 Extracting the low-frequency mesh

This is spectral mesh filtering - the 3D geometry equivalent of a low-pass filter in audio. Want to smooth a noisy mesh? Kill the high-frequency Eigen functions.

Any scalar function f on the mesh decomposes as:

To keep only the first K smooth Eigen functions:

For a 3D mesh, apply this independently to x, y, and z coordinates:

6 Python implementation

Here's the full pipeline - clean, commented, and ready to drop into your project:

import numpy as np
from scipy.linalg import eigh

# ── Step 1: Build Laplacian ─────────────────────────
def build_laplacian(n_vertices, edges):
    """
    edges: list of (i, j) vertex index pairs
    Returns L: (N, N) combinatorial Laplacian matrix
    """
    L = np.zeros((n_vertices, n_vertices))
    for i, j in edges:
        L[i, j] += 1       # neighbor gets +1
        L[j, i] += 1       # symmetric
        L[i, i] -= 1       # subtract degree on diagonal
        L[j, j] -= 1
    return L

# ── Step 2: Compute Eigen functions ─────────────────
def compute_Eigen functions(L):
    """
    Returns eigenvalues sorted ascending + Eigen functions.
    Each column of Eigen functions is one Eigen function.
    """
    eigenvalues, Eigen functions = eigh(L)
    return eigenvalues, Eigen functions

# ── Steps 3+4: Low-frequency mesh extraction ───────
def low_frequency_mesh(vertices, Eigen functions, K):
    """
    vertices:       (N, 3) xyz positions
    Eigen functions: (N, N) matrix - columns are Eigen functions
    K:              how many Eigen functions to keep (low-pass)
    Returns smoothed (N, 3) vertex positions
    """
    # Keep only K smoothest Eigen functions
    F_K = Eigen functions[:, :K]        # (N, K)

    # Project: cₖ = fₖᵀ · vertices
    coeffs = F_K.T @ vertices           # (K, 3)

    # Reconstruct from K Eigen functions only
    vertices_smooth = F_K @ coeffs     # (N, 3)
    return vertices_smooth

# ── Usage ──────────────────────────────────────────
# edges    = [(0,1), (1,2), ...]   from your mesh
# vertices = np.array([...])       shape (N, 3)

L = build_laplacian(len(vertices), edges)
eigenvalues, Eigen functions = compute_Eigen functions(L)

# Strong smoothing - keep only 20 Eigen functions
smooth = low_frequency_mesh(vertices, Eigen functions, K=20)

# Gentle smoothing - keep 200
gentle = low_frequency_mesh(vertices, Eigen functions, K=200)
